Add a Camera to OEM Porsche 911 Coupe (2019-2024) With PCM4.1/ PCM5.0/ PCM 6.0 Systems
Add a Camera to OEM Porsche 911 Coupe (2019-2024) With PCM4.1/ PCM5.0/ PCM 6.0 Systems
Couldn't load pickup availability
This interface is a camera add on kit which allows you to add an aftermarket front and/ or rear view camera whilst retaining the use of your factory head unit on select Porsche models with PCM4.1/ PCM5.0/ PCM 6.0 navigation systems (For specific models please view Vehicle applications). This system is specifically designed for use on vehicles without a factory camera input. Following the simple installation process the camera image can be automatically viewed via reverse gear or manually through the vehicle’s controls.
PLEASE NOTE: This is a special product order which we make take longer to arrive.
Add a front and/or rear camera to Porsche cars ( PCM4.1/ PCM5.0/ PCM 6.0 ) navigation systems with this plug and play camera interface.
Product Features
- Video feeder for factory infotainment systems
- 1 FBAS rear view camera video input
- 1 FBAS front camera video input
- 2 FBAS video inputs for retrofit devices (e.g. USB player, DVB-T2 tuner, ...)
- Automatic switching to rear view camera input when reverse gear is engaged
- Automatic front camera switching after reversing for 10 seconds
- Distance lines for rear view camera can be activated (not available for all vehicles)
- PDC can be activated (not available for all vehicles)
- Image activation while driving (ONLY for input video)
- Video inputs NTSC compatible
Suitable for the following Porsche models:
| Panamera (971) model year from 2017 | PCM 4.1 (Harman) with 12.3 inch monitor |
| 911 (992) model year from 2019 | PCM 5.0 (Alpine) with 12.3 inch monitor |
| Cayenne E3 (PO536) model year from 2018 | PCM 5.0 (Alpine) with 12.3 inch monitor |
| Cayenne Coupé model year from 2019 | PCM 5.0 (Alpine) with 12.3 inch monitor |
| Macan model year from 2019 | PCM 5.0 (Alpine) with 12.3 inch monitor |
| Taycan model year from 2019 | PCM 5.0 (Alpine) with 12.3 inch monitor |
| 911 (992) model year from 2022 | PCM 6.0 (Aptiv/Deplphi) with 12.3 inch monitor |
Compatibility notes
| Video only | The interface does NOT feed in audio signals. To feed in audio signals, a factory audio AUX input or an FM modulator can be used. If 2 AV sources are connected, additional electronics are required for audio switching. |
| Factory rear view camera | Automatic switching to RVC only as long as reverse gear is engaged. Additional electronics are required to delay the downshift. |
| After-market front camera | Switching to the front camera occurs automatically after disengaging reverse gear for 10 seconds. Manual switching to the front camera is also possible using the button. |
| Distance lines and PDC | The display of the guide lines and the optical PDC display does not work in all vehicles. |
| Video input signal | Only NTSC video sources compatible. |
Connections
- Image input: 4-pin HSD
- Power: open cable ends
- CAN-Bus: Plug & Play (Quadlock use)
- Video inputs (2x): RCA jacks
- Rear view camera input: RCA jack
- Front camera input: RCA jack
